Primary school of Ramps CHAP. 50 – Cannot just relay on support legs

Incorrect usage examples for using support legs

When we make the support legs, we always use the height informed by the customer, and then evaluate it based on the terrain in the photo, and then reduce it by at least 1 CM. It will not be too high or just right. It is suitable for any scene that requires the use of ramps.

The reasons are as follows:

  • Measurement error. If the support leg is too short, it can be raised. If it is too high, it cannot be lowered.
  • The ground is not absolutely level and must be reserved for customers to make fine adjustments.

The support legs were adjusted too high, resulting in insufficient force on the upper tongue plate. After the front wheel broke away from the plate, the rear wheel rolled and fell over completely. On the other hand, the upper tongue plate is pressed tightly by the weight because there is no support legs, unless step on it.

In terms of accessibility, we often see customers adjusting the support legs of half-fold ramps too high, resulting in a bulge in the middle of ramp. The right solution is to balance the force on the upper and lower ends and the supporting feet, or it would be better to adjust it a little lower. It doesn’t matter if the bottom of the foot is 1 CM away from the ground. As long as a person and the weight of the wheelchair are pressed up, the slope plate will sink and the feet will touch the ground. This method can ensure that there is sufficient pressure on both ends and allow the supporting feet to play their due role.

Continue reading Primary school of Ramps CHAP. 50 – Cannot just relay on support legs

Ramp primary school CHAP.49 Board length is not equal to Slope length

Board length is not equal to Slope length

A while ago, I had a long online discussion with the Kaohsiung Supervisor on the issue of ramp length and board length. Although the Supervisor did not make any requirements in the end, as a leading company, it is necessary to correct mistakes and establish industry standards.
For a long time, the length marked on the front and rear folding, left and right folding and single-piece ramp boards is the length of the ramp board from beginning to end, for example BJ121 our product, it means board length total is 121 CM(tongue plate 9 CM included) but the real slope length actually is 112 CM because the head tongue plate is on the upper staircase. We can’t see it as part of slope. In paper, official document tell the need is 121 CM, our BJ121 is 9 CM short actually but everybody do this.

Continue reading Ramp primary school CHAP.49 Board length is not equal to Slope length

Ramp Primary School CHAP 48 Electric remote winch

Portable ramps collocation and electric remote winch go together

In an aging society, there are more and more cases of elderly care. Daughters pushing their fathers and foreign workers with poor physical strength are also often encountered. After the previous introduction of wheelchair boosters, dozens of them have been sold, but after all, they have their limitations, such as steep slopes. No. The power is too small. The tire area is too small, which leads to problems such as insufficient grip. After all, the wheelchair booster is not designed to climb steep slopes. Continue reading Ramp Primary School CHAP 48 Electric remote winch

Ramp Primary School CHAP 47 Fixed wheelchair ramp

Fixed wheelchair ramp

In a scene where there are stairs first and then there is an elevator, some fire hydrants are next to the stairs, and regulatory factors cannot block the fire hydrants. Some people want to not block the electricity meter at all, or the width of the stairs is already very narrow and they do not want to be blocked by wall-mounted slopes. The thickness of the board takes up space, and the residents don’t like to move the movable ramp board around. There are also storage space issues and considerations of theft. We are very aware of this powerless dilemma.
Continue reading Ramp Primary School CHAP 47 Fixed wheelchair ramp

Ramp Primary School CHAP 44 Load test competition of different aluminum board

Load test competition of different aluminum board

I often hear dealers ask why my wheelchair aluminum alloy ramp plate is so stable, and I often hear customers ask me how thick my aluminum alloy plate is? I really don’t know how to answer this question, so I made this video today to explain it.

In this era, even cars are not as thick as before. The thicker and heavier they are, the worse the fuel consumption will be. The emphasis is on active and passive defense.

The aluminum alloy ramp plate for wheelchairs needs to be movable and lightweight. Under this premise, strengthening the load-bearing structure is the right solution!

Otherwise, even if the 6 mm aluminum plate is twice as thick, it will still be soft. Once the thickness is increased until it is satisfactory, the weight will be terrible huge.

Continue reading Ramp Primary School CHAP 44 Load test competition of different aluminum board

Exclusive model Cross threshold ramp with folding tongue panel

Cross threshold ramp with folding tongue panel

2022/12/21 preview. And we will show you this ultimate cross threshold ramp MZ-2. Let’s watch the video. If you don’t have to move the cross threshold ramp after using. This model will be more convenient. No matter which model of the Taiwan Ramp Experts’ cross threshold ramps, your slide rail threshold will not be deformed, don’t save a small amount of money and spend a lot of money. Continue reading Exclusive model Cross threshold ramp with folding tongue panel

Introduction to the soft X-threshold ramp board

Introduction to the soft X-threshold ramp board

X-threshold ramp have been selling abroad for a while. The grass is always greener on the other side of the fence. Taiwan Ramp experts tested this X-threshold ramp actual use of this commercially available aluminum checker plate/ We will also follow up on this. I will make videos of pushing wheelchairs in two other sizes so that everyone can see how soft they are. Continue reading Introduction to the soft X-threshold ramp board

Video tutor: how to measure bathroom threshold height

How to measure bathroom threshold height

The most requirement is potty chair and bath chair want to cross bathroom threshold. Customize bathroom threshold we need three figures:

1. The threshold’s smallest clear width and height of bathroom’s outside.

2. The threshold’s smallest clear width and height of bathroom’s inside.

3. The threshold’s smallest clear width and width  of facing ceiling side.

The detail measure method please watch the video tutor:

CYHB – Taiwan Ramp Expert

web : https://365freego.us

TEL : +886-800-222-666

YouTube Channel : https://www.youtube.com/channel/UC5lO2znBXE8FzdhOUUaRL_Q

Video Tutor: Floor-to-ceiling windows slide rail threshold measurement method

Floor-to-ceiling windows slide rail threshold measurement method

Floor-to-ceiling windows slide rail threshold is very often. The customize wheelchair we need three figures:

1. The slide rail threshold will have many walls or points. You have to find the highest wall to be the measurement base point. From this highest base point to measure outside height and inside height. If the base point is wrong or the measurement is not level, the figures will be incorrect and the result is your threshold ramp would not be level too.

2. The threshold cross width must include all thresholds especially is the small concrete threshold.

3. In case to avoid ramp is too wide. The clear width must get the smallest clear width.

The detail measurement method. Please watch the video.

CYHB – Taiwan Ramp Expert

web : https://365freego.us

TEL : +886-800-222-666

YouTube Channel : https://www.youtube.com/channel/UC5lO2znBXE8FzdhOUUaRL_Q

Ramp Primary School CHAP 43 Ramps for commercial use

Ramps for commercial use

Taiwan Ramp Expert not just deal with barrier-free environment improvement and also business case or life style adjustment.

You might not believe the height difference not just bother wheelchair but also the others like cargo moving. We’d like to talk about this case. The Genesis social welfare foundation. We believe client’s requirement is pushing a cart with cargo up-and-down. This is requirement through the whole communication period. It’s not a big deal to Taiwan Ramp Expert. We have too many experiences for kind of case. Finally, the specification was confirmed. The proposal is one Half-fold-REV Ramps with Aluminum alloy platform. Only two staffs will push the cart up-and-down ramp channel. The rest staffs will walk another staircase. For this, we also build a portable 3 rises staircase for staffs use.

But, we figure out the real story is not what we think. The cart is not a simple cart. The cargo on cart is a barrel. A barrel loaded with traditional grilled sweet potatoes.  The landing of Aluminum alloy platform is too small not enough for this barrel cart.

The site photo of first delivery as below: Continue reading Ramp Primary School CHAP 43 Ramps for commercial use
